Brand Name: | Cushion Pack |
Depth: | 31" |
Width: | 30" |
Height: | 43" |
Weight: | 755 Lbs |
Shipping Weight in Plywood Crate: | 763 pounds |
Cardboard Thickness: | Up to 0.9" |
Creates 2 Types of Packing Material: | Yes. Adjustable to make flat sheets or pre-cushioned material - A Cushion Pack Exclusive! |
Cutting Width of Cardboard: | 16.9" |
Electrical: | 240V, 60 Hz, 3 Phase (30 amp circuit breaker per phase tied together); or 480V, 3 Phase, 60 Hz (20 amp circuit breaker per phase tied together). This machine is thermally protected by an overload current sensor which detects an overload situation. |
Electrical Continued: | When the current sensor detects an overload the machine automatically shuts down. The red reset button has to be pressed to clear out the machine, then press reverse to clear jam, then shredding is resumed. |
Emergency stop switch: | Yes |
Features: | Best in class, high density, high strength steel chain with heavy duty industrial strength gear box. |
Horsepower: | 4.0 kW / 5.36 HP |
Horsepower Alternate: | 480 Volt Available 4.8 kW / 6.43 HP at additional cost |
Loading Length-Cardboard Size: | Endless |
Noise Level (dB): | Noise under load is 78 dB(A) , Noise under NO load is 64 dB(A) |
Push Button Control Start/Stop and Reverse Functions: | Yes |
Push Button Reset Feature: | Yes |
Speed: | 52 feet per minute |
Throughput rate: | 6-10 cubic yards per hour |
